| • | Stimulus current - up to 5mA (30V) |
| • | Stimulus duration - up to 40 min |
| • | Stimulus Type ; |
| • | tDCS |
| • | tACS |
| • | tRNS |
| • | tDCS-Sham |
| • | tPCS |
| Number of channels | : | 1 |
| Stimulation Channel | ||
| Pulse type : Current | : | Current |
| Impedance measurement error (patient circuit) within the range 0.5 to 12.0 kΩ at stimulation current 0.3 mA to 5 mA current |
: | ± (10% of the specified value +200 Ω) |
| Maximum voltage at channel output (without load) | : | not more than 38 V |
| Pulse amplitude | : | 0 to 2 mA |
| Adjustment step for pulse amplitude | : | 25 µA |
| Session duration | : | 15 s to 40 min |
| Session duration adjustment step | : | 1 s |
| Stimulation mode/pulse waveform: | ||
| • tDCS | : | transcranial direct current stimulation with adjustable amplitude, ramp up/down time, and sham stimulation option |
| • tPCS | : | transcranial pulsed current stimulation by monophasic square pulse waveform with adjustable amplitude, duration, and interpulse interval |
| • tACS | : | transcranial alternating current stimulation by sinusoidal, bipolar square or custom (user-defined) pulse waveform with adjustable amplitude, offset, and start phase |
| • tRNS | : | transcranial random noise stimulation by noise-like pulses with adjustable amplitude and offset |
| Direct current in patient circuit at disabled stimulation output | : | not more than 10 µA |
| Sampling period of stimulation current: • tDCS |
: | 2 ms |
| • tACS | : | 30 µs |
| • tRNS | : | 100 µs |
| Stimulation Mode Parameters | ||
| tDCS — transcranial direct current stimulation | ||
| Current ramp up/down time | : | 0 to 2 min |
| Adjustment step for current ramp up/down time | : | 1 s |
| Current ramp up/down time during sham stimulation | : | 0 to 2 min |
| Adjustment step for current ramp up/down time during sham stimulation | : | 1 s |
| tPCS — transcranial pulsed current stimulation | ||
| Frequency | : | 1 to 250 Hz |
| Frequency adjustment step: | : | |
| • within the range from 1.00 to 10.00 Hz | : | 0.01 Hz |
| • within the range from 10.0 to 250.0 Hz | : | 0.1 Hz |
| Offset | : | – 1000 to 1000 µA |
| Offset adjustment step | : | 10 µA |
| Start phase Start | : | 0 to 355° |
| phase adjustment step | : | 5° |
| Pulse waveform | : | sinusoidal, square, custom |
| tRNS — transcranial random noise stimulation | : | |
| Offset | : | – 1000 to +1000 µA |
| Offset adjustment step | : | 10 µA |
| General Specifications | ||
| Connection to PC | : | USB 2.0 |
| Maximum number of sessions | : | 250 |
| Power supply | ||
| one 6LR61 battery (nominal voltage – 9 V, nominal capacity – not less than 550 mAh) | ||
| (5±0.25) V, from 300 mA (PC) | ||
| Power consumption | : | not more than 2.5 W |
| Personal Computer Requirements | ||
| Operating system : • Windows 10×64/×86 • RAM: 2 GB and more • free disk space (hard drive): not less than 50 MB • Intel Core i3-6300 or AMD Ryzen 3 3200G processor and more powerful • USB 2.0 |
| Main Unit tDCS | : | 1 |
| USB Cable | : | 1 |
| Cable for electrode Connection | : | 2 |
| Conductive Silicone electrode | : | 2 |
| Spontex holding bag | : | 2 |
| Electrode Fixation | : | 2 |
| Rubber Tape Fixator | : | 2 |
| Manual Book | : | 1 |
| Software Neurostim | : | 1 |
| Laptop | : | 1 |
